ATC SCM150ASL Pro Studio Monitor

ATC SCM150ASL Pro delivers ultra precision and power. With ATC’s 25mm/1” Dual Suspension ‘S-Spec’ Tweeter, full “SL” spec 15˝/375mm bass driver, and ATC 75mm “Super Dome” mid driver, they redefine studio excellence. Grounded source 350W Tri-Amp Pack, LF contour control, clip indication, and 6-year warranty.

ATC SCM150ASL Pro Studio Monitor

Introducing the ATC SCM150ASL Pro Studio Monitor, a masterpiece of audio engineering that redefines professional sound reproduction. Anchored by the ATC 25mm/1” Dual Suspension ‘S-Spec’ Tweeter, it captures intricate high-frequency details with unparalleled precision. The full “SL” spec 15˝/375mm bass driver produces profound, accurate bass while maintaining remarkable sonic fidelity. The ATC 75mm “Super Dome” mid driver breathes life into vocals and instruments, ensuring an authentic sonic experience.

Enveloping these components is the on-board ATC grounded source 350W Tri-Amp Pack, meticulously designed to optimize power distribution and coherence across the frequency spectrum. The LF contour control empowers users to tailor the low-frequency response to their environment, while the clip indication feature safeguards against audio distortion, maintaining pristine sound quality even at higher levels.

Reassurance is embedded in the product with a 6-year warranty, reflecting the monitor’s robust construction and the manufacturer’s commitment to quality. The ATC SCM150ASL Pro Studio Monitor stands as a pinnacle of sound innovation, catering to professionals and enthusiasts who demand nothing less than perfection. Elevate your studio experience and embrace a new dimension of sonic excellence.

Specifications

Drivers: HF 1″/25mm, Mid 3″/75mm, LF 15″/375mm
Amplitude Linearity (±2dB): 60Hz-17kHz
Cut-off Frequencies (-6dB, free-standing): 25Hz, 25kHz
Horizontal Dispersion: ±80°, Coherent
Vertical Dispersion: ±10°, Coherent
Max. Continuous SPL (1 metre): 117dB
Crossover Frequencies: 380Hz, 3.5kHz
Audio Input: Rear panel mounted female xlr (pin 2 +)
Input Sensitivity: 1V
Input Sensitivity Trim: 0dB to -6dB/1V – 2V (continuously variable via rear panel trimmer)
Input Impedance: Balanced > 10kΩ
Amplifier Output: Bass 200W, Mid 100W, High 50W
Filters: Even Order Critically Damped
Overload Protection: Active FET momentary gain reduction plus thermal tweeter protection
Front Panel Indicators: Power On indicator, Gain Reduction warning
LF EQ: 0dB to+6dB @ 40Hz (continuously variable via rear panel trimmer)
Dimensions (HxWxD): 884 x 498 x 568mm (34.8˝ x 19.6˝ x 22.4˝) Depth with amplifier at rear adds 3˝
Weight: 75kg / 165lbs

User Manual

Download the User Manual in PDF format.

Ordering

SKU SCM150ASLP Categories , Tag

$37,054 Inc GST
