Autex Quietspace Nude Panel 50mm

Autex Quietspace Nude Panel 50mm

Autex Quietspace Nude Panel 50mm is engineered for superior sound absorption and balanced acoustic design; Quietspace Nude Panel 50mm is a premium sound solution for wall and ceiling applications. Utilising the latest technology, any image or design can be recreated as a unique acoustic detail, custom panel or artwork.

The Autex Quietspace Nude Panel 50mm is an ideal alternative to fabric wrapped frames, each acoustic panel is lightweight, semi-rigid, impact resistant and incredibly durable. This unique design allows interior designers to explore new horizons and break established boundaries, whilst achieving high levels of sound absorption.

Ordio Acoustics work closely with interior designers around Australia to achieve the overcome the sometimes challenge between interior design, aesthetics and overall logistics of acoustic treatment solutions within the corporate, government and industrial spaces.

Quietspace Nude Panel 50mm is supplied to site in sheet form that can be cut-in and framed on-site eliminating issues with on-site variations in wall size and shape that have traditionally posed problems for fabric wrapped panels manufactured and finished off-site.

Autex Quietspace 50mm Nude Panel is made from 100% recyclable polyester and manufactured under Autex’s ISO 14001accredited Environmental Management System. Quietspace Nude Panel 50mm contains a minimum of 60% post-consumer recycled material (PET bottle-flake).

Autex Quietspace Nude Panel 50mm Acoustic Performance

Autex Quietspace Nude Panel 50mm Panel is is specifically designed to reduce and control reverberated noise and echo in building interiors. Minimum Noise Reduction Coefficient 0.85.

Absorption Coefficient according to ISO 354 University of Auckland Testing Service

  • Autex Quietspace Nude Panel 25mm – test no. T0712-18
  • Autex Quietspace Nude Panel 50mm – test no. T1228-8
  • Autex Quietspace Nude Panel 75mm – test no. T1905-4
  • Autex Quietspace Nude Panel 100mm – test no. T1905-5

Autex Quietspace Nude Panel 50mm Applications

  • Refined acoustic surface for framed modular office partition panelling
  • Can be direct fixed to ceilings and walls as a functional and decorative acoustic panel
  • Sophisticated, high-performance acoustic panel for sound control in interior spaces

Terms of Sale

  1. I understand that there are no refunds or exchanges for this product.
  2. I accept the manufacturing and freight lead time when placing an order for this product.
  3. I understand that the colours on my screen may not match the actual product.
  4. I understand this product may have a MOQ and will order no less than the MOQ.

Autex Quietspace Nude Panel 50mm Colour Options

Nude Black
Nude Black
Nude Grey
Nude Grey
Nude White
Nude White

Disclaimer: The colors displayed on this website have been provided by Autex for reference purposes only. Please note that these colors are intended as a guide and may not accurately represent the true color. For a more precise depiction of color, we recommend requesting a color swatch.

Specifications

SKU Autex-Quietspace-50mm-Nude-Panel Categories ,
  • Product Name: Quietspace® Panel
  • Composition: 100% Polyester Fibre (PET)
  • Panel Dimensions: 1200 mm x 2400 mm
  • Tolerance: (+ 5 mm) x (+ 10 mm)
  • Light reflectance: White Quietspace Panel is suitable for indoor use only and has a light reflectance value of 83 (measured in accordance with BS 8493:2008+A1:2010).
  • Thermal performance: (Internally tested by Autex Lab) 25 mm: R0.6 (@23°C) 50 mm: R1.4 (@23°C) 75 mm: R1.9 (@23°C) 100 mm: R2.4 (@23°C)

Product Documentation

Download Product Documentation

Ordering

  • Engineered to absorb a minimum of 85% of the sound energy it meets
  • Can be overlaid with Vertiface for a decorative feature
  • Broadband absorber
Lead Time: 7 – 10 Days
Quantity: MOQ: 3x Panels

$289 Inc GST
