ATC SCM50ASL Pro Studio Monitor

ATC SCM50ASL Pro Studio Monitors deliver superior sound via ATC’s 25mm/1” Dual Suspension ‘S-Spec’ Tweeter, full “SL” spec 9˝/234mm bass driver, and ATC 75mm “Super Dome” mid driver. Packed with a grounded source 350W Tri-amp pack, LF contour control, clip indication, and a 6-year warranty.

The ATC SCM50ASL Pro Studio Monitor is available to audition in our showrooms.

ATC SCM50ASL Pro Studio Monitor

Discover the epitome of audio refinement with the ATC SCM50ASL Pro Studio Monitors, where precision engineering and state-of-the-art components unite to create an unparalleled sonic experience. At the core of these monitors lies the ATC 25mm/1” Dual Suspension ‘S-Spec’ Tweeter, a pinnacle of high-frequency reproduction that captures intricate details and nuances with remarkable clarity. Complementing this is the full “SL” spec 9˝/234mm bass driver, which not only delivers deep and impactful bass but also maintains exceptional accuracy across the frequency spectrum.

The midrange of the ATC SCM50ASL Pro is entrusted to the ATC 75mm “Super Dome” mid driver, renowned for its ability to render vocals and instruments with lifelike realism and a captivating presence. Elevating the performance even further, the onboard grounded source 350W Tri-amp pack ensures each driver receives its dedicated power, resulting in a seamless integration of frequencies and a dynamic listening experience.

Tailoring the audio to the specific room environment is made effortless by the LF contour control, allowing users to adjust the low-frequency response to achieve optimal balance. The clip indication feature acts as a safeguard against audio distortion, providing a clear indication when the system is nearing its limits.

To instill unwavering confidence, the ATC SCM50ASL Pro Studio Monitors come with a 6-year warranty, a testament to their durability and the manufacturer’s commitment to quality. Crafted with meticulous attention to detail, these monitors stand as a testament to ATC’s legacy of audio excellence, serving as the ideal companions for audiophiles, producers, and sound engineers alike. Experience the pinnacle of sound reproduction and indulge in a world of sonic intricacies like never before with the ATC SCM50ASL Pro Studio Monitors.

Specifications

Drivers: HF 1″/25mm, Mid 3″/75mm, LF 9″/234mm
Amplitude Linearity (±2dB): 70Hz-17kHz
Cut-off Frequencies (-6dB, free-standing): 38Hz, 25kHz
Horizontal Dispersion: ±80°, Coherent
Vertical Dispersion: ±10°, Coherent
Max. Continuous SPL (1 metre): 112dB
Crossover Frequencies: 380Hz, 3.5kHz
Audio Input: Rear panel mounted female xlr (pin 2 +)
Input Sensitivity: 1V
Input Sensitivity Trim: 0dB to -6dB/1V – 2V (continuously variable via rear panel trimmer)
Input Impedance: Balanced > 10kΩ
Amplifier Output: Bass 200W, Mid 100W, High 50W Filters : Even Order Critically Damped
Overload Protection: Active FET momentary gain reduction plus thermal tweeter protection
Front Panel Indicators: Power On indicator, Gain Reduction warning
LF EQ: 0dB to+6dB @ 40Hz (continuously variable via rear panel trimmer)
Dimensions (HxWxD): 716 x 351 x 400mm (28.2˝ x 13.8˝ x 18.8˝) Depth with amplifier at rear adds 3˝
Weight: 49kg / 107.8lbs

User Manual

Download the User Manual in PDF format.

Ordering

SKU SCM50ASLP Categories , Tag

$28,140 Inc GST
